SMD2835 Diffuse Reflection Backlight Led With Lens
  • SMD2835 Diffuse Reflection Backlight Led With Lens
  • SMD2835 Diffuse Reflection Backlight Led With Lens
  • SMD2835 Diffuse Reflection Backlight Led With Lens
  • SMD2835 Diffuse Reflection Backlight Led With Lens
  • SMD2835 Diffuse Reflection Backlight Led With Lens

SMD2835 Diffuse Reflection Backlight Led With Lens

Item No.: HBMJ-TJ-46-6
LED 2835 backlit light strip, it is popular used for slim fabric light box(depth from 40mm-80mm), 180 degree beam angle, low decay, there is no ribbon shadow on the light box once light up. Ajustable LED light type is specialized design for customers.
INQUIRY
SMD2835 DC12V LED backlit light lattice strips
LED2835 backlit light strip with lens,Taiwan Epistar chip which is popular used for slim fabric light box(depth from 40mm-80mm), 180 degree beam angle, low decay, there is no ribbon shadow on the light box once light up.
Ajustable LED light type is specialized design for foreign customers, you may ajust the strips distance freely accoding to your requirements.It is with CE/RoHS certificates.


Product parameters:
 Model  diffuse reflection SMD2835 (non-waterproof)
 Led  source  back-light
 Type  lattice  light strip
 Body Material  aluminum
 Function  for light box,Lighting
 Color temperature  6000K-7000K
 Emitting color  RGB/ white Top quality PCB with efficient heat dissipation
 Light Angle  170℃
 Length  50CM, 6  lamp beads
 Lamp power  10.8W/meter
 CRI(Ra>)  80
 Input voltage  DC24V
 Lamp luminous flu(lm)  400
 Working lifetime(hour)  50000-70000
 IP rating  IP67
Working temperature   -40-60 High quality 2835 chip
 Led chip brand  epistar
 OEM & ODM  both
 Certification  UL,CE,ROHS
 Free Sample  one sample is available
 MOQ  1 meter
 Packaging details  carton+splint wooden frame
 FOB price  USD 5.54/per meter
 Supply ability  100000  meters/ per week Top quality PMMA lens
